TVLogic LXM-240U 23.8" DCI/UHD 4K Monitor

TVLogic LXM-240U 23.8" DCI/UHD 4K Monitor

Name: TVLogic LXM-240U 23.8" DCI/UHD 4K Monitor
Brand: TV Logic
SKU: LXM-240U
Price: 28743.06 AED
Availability: BackOrder

Reference LXM-240U

Special Order -

AED28,743.06

Tax excluded

SKU : #LXM-240U

Key Features :

23.8" Display, 3840 x 2160 Resolution
4 x 3G/12G-SDI I/O, 1 x HDMI Input
1200 cd/m² Bright, 1200:1 Contrast
Wide Color Gamut, Quad/Dual View Tools
HDMI/SDI Cross Conversion
HDR/SDR Comparison
Quad-Link 3G-SDI Input/Output
Speaker & Headphone Output
Waveform, Vectorscope, Histogram

TVLogic LXM-240U 23.8" DCI/UHD 4K Monitor

The TVLogic LXM-240U is a premium UHD 4K monitor tailored for professional production environments. Featuring a bright and vibrant display, it delivers exceptional image quality with support for HDR emulation, encompassing a broad color gamut, extended dynamic range, and various gamma standards such as PQ, HLG, and SLog3. The monitor also supports 10-bit color depth, ensuring highly accurate color representation, and boasts a native resolution of 3840 x 2160 for stunning detail.

The LXM-240U accepts UHD 4K signals through its HDMI 2.0 input or four 12G-SDI inputs. Additionally, it supports video resolutions up to 1080p60 via its two 3G-SDI inputs. To facilitate multi-monitor setups, the monitor is equipped with 12G-SDI and 3G-SDI quad-link loop outputs, enabling seamless signal routing for dual or quad-view configurations.

What's Included :

---------------------------------------------------

TVLogic LXM-240U 23.8" UHD 4K Monitor
AC Power Cable
Desktop Stand for easy setup
USB Port Cover
1-Year Limited Manufacturer Warranty

Video I/O: 4x BNC (12G-SDI) Input 1x HDMI 2.0 Input 4x BNC (12G-SDI) Loop Output 1x BNC (Unspecified SDI) Output
Mobile App Compatible: No
Dimensions: 21.75 x 14.19 x 3.78" / 55.25 x 36.04 x 9.59 cm 23.07 x 15.28 x 5.9" / 58.61 x 38.82 x 15 cm, Including Stand
Weight: 22.0 lb / 10 kg
Display Size: 23.8" / 60.5 cm
Resolution: 3840 x 2160
Touchscreen: No
Bluetooth: No
Screen Area: 20.70 x 11.64" / 52.57 x 29.57 cm
Panel Type: IPS-Type LCD
Aspect Ratio: 16:9
Viewing Angle: Horizontal: 178° Vertical: 178°
Maximum Brightness: 500 nits / cd/m2
Contrast Ratio: 1200:1
Dot Pitch: 0.137 x 0.137 mm
Bit Depth / Color Support: 10-Bit (1.07 Billion Colors)
Real-Time LUT Monitoring: SDR, HDR
Image Controls: Histogram, Vectorscope, Waveform
Audio I/O: 1x 1/8" / 3.5 mm Line Input
Built-In Speaker: No
Power I/O: 1x XLR 4-Pin (12 VDC) Input 1x IEC Input
Other I/O: 1x BNC (Reference) Input 1x RJ45 (LAN) 1x RJ45 (GPI) Input 1x RJ45 (RS-422) Input 1x RJ45 (RS-422) Output
Media/Memory Card Slot: No
Video Signal Conversion: HDMI to SDI
HDR Compatibility: Hybrid Log Gamma
Pixels Per Inch (ppi): 185 ppi
