SWIT 5.5-inch FHD Waveform LCD Monitor

Name: SWIT 5.5-inch FHD Waveform LCD Monitor
Brand: SWIT
SKU: S-1053F
Price: 2199 AED
Availability: BackOrder

0 Reviews

| Ask a question

SKU: S-1053F

Special Order 1-2 Weeks

AED2,199.00

Tax excluded

SKU:S-1053F

Key Features

5.5” LCD, 1920×1080 full HD
Optical bonding LCD panel
All metal housing, thinner and robust
2K/3G/HD/SD-SDI input and loop out
HDMI input and converted to SDI out
16-ch Embedded audio meters with alert
Select any 2 audio channels to output
Waveform Y/Cb/Cr/R/G/B and single line
Vector scope, histogram R/G/B/Y

Secure payments

Ask an Expert

WhatsApp Chat | Email | +971 55 510 4251

Description

The S-1053F adopts a 5.5-inch LCD panel with LED backlight, optical bonding technical. The native resolution is Full HD 1920×1080, contrast 1000:1, and viewing angle is Horizontal: 160° / Vertical: 160°

Product Details

Compatibility: SWIT S-8972, S-8970, S-8770; Sony NP-F970, NP-F770
Color: 16.77 million colors
Dimensions: 5.9 x 3.5 x 1.2" (151 x 91 x 32 mm)
Weight: 13 oz (375 g)
Resolution: 1920×1080
Power Consumption: 12 W
Size: 5.5"
Aspect Ratio: 16:9 (4:3 adjustable)
Viewing Angle: Horizontal: 160°Vertical: 160°
Storage Temperature: 5 to 140°F (-15 to 60°C)
Display Area (H × V): 120.96×68.04mm
Input: BNC: 2K/3G/HD/SD-SDI HDMI 1.3 Micro-USB firmware upgrade
Output: BNC: 2K/3G/HD/SD-SDI loop output or HDMI converted to SDI output 1/8" (3.5 mm): SDI, HDMI, embedded audio output
Operating Voltage: Battery 6.5 to 24 VDC
