TVLogic 9" UHD 4K Input-Ready SDI/HDMI LCD Monitor

TVLogic 9" UHD 4K Input-Ready SDI/HDMI LCD Monitor

Name: TVLogic 9" UHD 4K Input-Ready SDI/HDMI LCD Monitor
Brand: TV Logic
SKU: LUM-095G
Price: 17042.72 AED
Availability: OutOfStock

0 Reviews

| Ask a question

SKU: LUM-095G

Out-of-Stock

AED17,042.72

Tax excluded

SKU : #LUM-095G

Key Features :

9" 1920 x 1080 LCD Monitor
4 x SDI Ports, 1 x HDMI Port
Supports Inputs up to UHD 4K Video
178° Viewing Angle
400 cd/m² Maximum Brightness
Native Full HD Resolution
Control via Buttons, RS-422, Remote
Various Image Monitoring Controls

Secure payments

Ask an Expert

WhatsApp Chat | Email | +971 55 510 4251

Description

Ideal for field monitoring applications, the 9" UHD 4K Input-Ready SDI/HDMI LCD Monitor from TVLogic supports both SDI and HDMI video at resolutions up to UHD 4K. Four SDI ports and one HDMI port natively support full HD resolutions while also supporting UHD 4K inputs. The LUM-0956 has a 178° viewing angle and maximum brightness of 400 cd/m² for increased visibility.

In the Box :

--------------------------------------------------

TVLogic 9" UHD 4K Input-Ready SDI/HDMI LCD Monitor
AC Power Cord
DC Power Adapter
Carry Handle
Table Stand
Camera Mount
Limited 2-Year Manufacturer Warranty (on Hardware)
Limited 1-Year Manufacturer Warranty (LCD Panel)

Product Details

Video I/O: 1x HDMI 2.0 Input 1x BNC (12G-SDI) Input 1x BNC (12G-SDI) Output 1x BNC (3G-SDI) Input 1x BNC (3G-SDI) Output
Mobile App Compatible: No
Display Size: 9.0" / 22.9 cm
Resolution: 1920 x 1080
Touchscreen: No
Wifi: No
Bluetooth: No
Screen Area: 7.82 x 4.40" / 198.72 x 111.78 mm
Panel Type: IPS-Type LCD
Aspect Ratio: 16:9
Viewing Angle: Horizontal: 178° Vertical: 178°
Maximum Brightness: 400 nits / cd/m2
Contrast Ratio: 750:1
Dot Pitch: 0.1035 x 0.1035 mm
Bit Depth / Color Support: 8-Bit (16.7 Million Colors)
Real-Time LUT Monitoring: HDR
Image Controls: Anamorphic De-Squeeze, Blue Only, Color Temperature Selection, Customizable Aspect Ratios, Focus Assist, H/V Delay, Image Flip, Vectorscope, Waveform
Embedded Audio: HDMI/SDI
Audio I/O: 1x 1/8" / 3.5 mm Input 1x 1/8" / 3.5 mm Output
Power I/O: 1x XLR 4-Pin (24 VDC) Input
Other I/O: 2x RJ45 (RS-422) Input/Output 1x RJ45 (GPI) 1x USB-A (Firmware) Input
Media/Memory Card Slot: No
HDR Compatibility: No
Pixels Per Inch (ppi): 244 ppi
