TVLogic F-7HS 7" High Luminance LCD Field Monitor

Name: TVLogic F-7HS 7" High Luminance LCD Field Monitor
Brand: TV Logic
SKU: F-7HS
Price: 8815.2 AED
Availability: InStock

Reference F-7HS

AED8,815.20

Tax excluded

SKU : #F-7HS

Key Features :

HDMI / SDI: Cross convert HDMI/SDI
HDR Expression with Normal Display Panel
3D LUT: Accept 17x17 CUBE File
Support Camera LUT for Log
1500 Nits in Outdoor Mode
1800 Nits in Max Brightness Mode

NEED HELP?

The F-7HS 7" Full HD Monitor is a High Brightness Field Monitor with Enhanced Sharpness, a 7" 1920x1080 resolution field monitor that offers Max Brightness of 1800nits with enhanced sharpness and peaking boost function via the refined image processing engine. With the high-quality picture and professional features, F-7HS shows the best performance anywhere.

In the Box :

------------------------------------

TVLogic F-7HS 7" High Luminance LCD Field Monitor

Video I/O: 1x HDMI Input 1x HDMI Loop Output 1x BNC Input 1x BNC Loop Output
1x HDMI Input 1x HDMI Loop Output 1x BNC Input 1x BNC Loop Output
Mobile App Compatible: No
No
Dimensions: 8.7 x 4.9 x 0.3" / 221 x 125 x 8.3 mm
Weight: 1.8 lb / 0.8 kg
Display Size: 7.0" / 17.8 cm
Resolution: 1920 x 1200
Touchscreen: No
Video Format: No
Power Consumption: 21 W (Maximum)
Mounting: 4x 1/4"-20 Female
Wifi: No
No
Bluetooth: No
No
DC Input Power: 6 to 34 VDC
Screen Area: 6.0 x 3.7" / 151.2 x 94.5 mm
Panel Type: LCD
Aspect Ratio: 16:10
Viewing Angle: Horizontal: 160° Vertical: 160°
Maximum Brightness: 1800 nits / cd/m2
Contrast Ratio: 1200:1
Dot Pitch: 0.0787 x 0.0787 mm
Bit Depth / Color Support: 10-Bit (1.07 Billion Colors)
Image Controls: Anamorphic De-Squeeze, Focus Assist, H/V Delay, Marker Color, Vectorscope, Waveform
Anamorphic De-Squeeze, Focus Assist, H/V Delay, Marker Color, Vectorscope, Waveform
Embedded Audio: SDI: 16-Channel HDMI: 2-Channel
SDI: 16-Channel HDMI: 2-Channel
Audio I/O: 1x 1/8" / 3.5 mm Headphone Output
1x 1/8" / 3.5 mm Headphone Output
Built-In Speaker: No
No
Other I/O: 1x USB-A (Firmware) Input
1x USB-A (Firmware) Input
Media/Memory Card Slot: No
No
PC Resolutions: 1920 x 1080 at 60 Hz 1280 x 1024 at 60 Hz 1280 x 800 at 60 Hz 1280 x 768 at 60 Hz 1024 x 768 at 60/70/75 Hz 880 x 600 at 60/75 Hz 640 x 480 at 60/75 Hz 640 x 400 at 70 Hz
1920 x 1080 at 60 Hz 1280 x 1024 at 60 Hz 1280 x 800 at 60 Hz 1280 x 768 at 60 Hz 1024 x 768 at 60/70/75 Hz 880 x 600 at 60/75 Hz 640 x 480 at 60/75 Hz 640 x 400 at 70 Hz
Video Signal Conversion: HDMI to SDI SDI to HDMI
HDMI to SDI SDI to HDMI
Operating Temperature: 32 to 104°F / 0 to 40°C
HDR Compatibility: No
Pixels Per Inch (ppi): 323 ppi
Gamma Curve: ARRI Log C, Canon Log, Sony S-Log, Sony S-Log 2, Sony S-Log 3
Video Standard Compliance: SMPTE 125M/274M/296M/425M-A/425M-B ITU -R BT.656
