TVLogic F-5A 5.5 Inch IPS On-Camera Monitor

TVLogic F-5A 5.5" IPS On-Camera Monitor with L-Series Type Plate

Name: TVLogic F-5A 5.5" IPS On-Camera Monitor with L-Series Type Plate
Brand: TV Logic
SKU: N278F-5A
Price: 4270 AED
Availability: OutOfStock

0 Reviews

| Ask a question

SKU: N278F-5A

Out-of-Stock

AED4,270.00

Tax excluded

SKU : N278F-5A

Compact 5.5" Full HD IPS field monitor with 500-nit brightness, 3G-SDI and HDMI connectivity, waveform/vectorscope, focus assist, HDR emulation and custom 3D LUT support. Its built-in Sony L-Series battery bracket makes it practical for professional camera monitoring across the UAE.

Key Features :

5.5" 1920 x 1080 IPS Display
Waveform, Vectorscope & Audio Meter
1000:1 Contrast Ratio
160° Viewing Angle
3G-SDI & HDMI Input/Output & Conversion
HDR Emulation of PQ, HLG & SLog3
Multiple Safety Area & Marker Functions
Supports Popular Camera LUTs
Integrated L-Series Battery Bracket
Lightweight, Durable Aluminum Chassis

Secure payments

Ask an Expert

WhatsApp Chat | Email | +971 55 510 4251

Description

TVLogic's F-5A 5.5" IPS On-Camera Monitor with L-Series Type Plate offers cinematic image quality in a sleek, compact form suitable for use as an EVF or onboard camera monitor. This monitor features a 1080p Full HD IPS display with 160° viewing angle and a contrast ratio of 1000:1. Monitoring functions include waveform, vectorscope, and 16-channel audio level meter displays. The versatile F-5A monitor has both 3G-SDI and HDMI inputs and outputs, enabling HDMI-to-SDI and SDI-to-HDMI conversion.

In the Box

TVLogic F-5A 5.5" IPS On-Camera Monitor with L-Series Type Plate
D-Tap Cable
L-Shaped BNC Adapter
Screen Protector
Camera Support
Limited 2-Year Warranty on Hardware
Limited 1-Year Warranty on Display Panel

Product Details

Video I/O: 1x BNC (3G-SDI) Input 1x HDMI Input 1x BNC (3G-SDI) Output 1x HDMI Output
Battery Type: 1x L-Series
Dimensions: 6.4 x 3.6 x 1.1" / 162.5 x 92 x 27.6 mm
Weight: 14.8 oz / 420 g
Display Size: 5.5" / 14.0 cm
Resolution: 1920 x 1080
Touchscreen: no
Power Consumption: 10 W
DC Input Power: 12 to 34 VDC at 0.65 A
Screen Area: 4.83 x 2.72" / 122.7 x 69 mm
Panel Type: IPS-Type LCD
Aspect Ratio: 16:9
Viewing Angle: Horizontal: 160° Vertical: 160°
Maximum Brightness: 500 nits / cd/m2
Contrast Ratio: 1000:1
Dot Pitch: 0.0213 x 0.063 mm
Bit Depth / Color Support: 8-Bit (16.7 Million Colors)
Real-Time LUT Monitoring: SDR
Image Controls: Blue Only, False Color, Focus Peaking, H/V Delay, Image Flip, Screen Markers, Underscan, Vectorscope, Waveform, Zebra
Embedded Audio: HDMI SDI
Audio I/O: 1x 1/8" / 3.5 mm Headphone Output
Built-In Speaker: 1
Power I/O: 1x Barrel Input
Other I/O: No
Media/Memory Card Slot: No
PC Resolutions: 1920 x 1080 at 60 Hz 1280 x 1024 at 60 Hz 1280 x 800 at 60 Hz 1024 x 768 at 60/70/75 Hz 800 x 600 at 60/75 Hz 640 x 480 at 60/75 Hz 640 x 400 at 70 Hz
Video Signal Conversion: HDMI to SDI SDI to HDMI
Operating Temperature: 32 to 77°F / 0 to 45°C
Storage Temperature: -4 to 140°F / -20 to 60°C
Material of Construction: Aluminum
